lThe case made of high intensity PC and antistatic rubber makes the instrument not only sturdy and durable but also compact and light-weight;

lThe instrument is equipped with most advanced Li-polymer rechargeable battery, and the ultra-high-capacity battey can ensure long-time continuous operation of the instrument with the longest time up to 12 hours;

lThe extra-loud buzzer,extra-bright LED, and high capacity vibrating motor ensure that the users can get the alarm signals of the instrument timely and effectively in any severe working environment.

lThe ultra-large LCD screen is equipped with ultra-bright backlight, convenient for the users to read the readings of 4 gases simultaneously;

lThe GS40 instrument can not only display the concentration of a dangerous gas in real time but also calculate the TWA and STEL values of a toxic gas and display the results on the LCD as per corresponding instructions;

lThe function of 1,000-hour data recording enables you to better learn about the change of its working environment and its performance;

lThe internal infrared communication port enables you to read the data and modify the instrument settings conveniently via your computer;

lIts Protection Classification can exceed IP65;

lOne key recovery function assures you from worrying about wrong operations.

Part No.

90004000

Gas Detected

4 kinds of gas simultaneously

Sampling Method

Diffusion(or with sampling pump)

Gas Sensor

Electrochemical sensor

Catalytic sensor

Infrared sensor

PID sensor

Power

High capacity Li-polymer battery

Voltage, 3.7V

Capacity, 1100 mAh

Run Time

15 hours

Display

Displayed with large screen LCD

Alarm method

Sound, light and vibration alarms

Record (Optional)

Data recording time: 1000 hours

Data recording interval: 1 minute

Protection Classification

IP65

Environment Temperature

-20℃~ 50℃

Environment Humidity

15%~ 95% relative humidity (standard)

Explosion-Proof

Ex ia IIC T6 or Ex ib I

Size

95mm*50mm*22mm (length*width*height)

Weight

210 g

Materials of the cases

High intensity PC and antistatic rubber

Gas detected

Sensor Principle

Measure Range

Definition Rate

Response Time

Combustible gas(LEL)

Catalytic

(0~~100) %LEL

1 %LEL

30s

Combustible gas(LEL)

Infrared

(0~~100) %LEL

1 %LEL

30s

Methane(CH4)

Infrared

(0~~5.00) %Vol.

0.01 %Vol.

30s

(0~~100) %Vol.

0.1 %Vol.

30s

Oxygen(O2)

Electrochemical

(0~~30.0) %Vol.

0.1%Vol.

30s

Carbon Monoxide(CO)

Electrochemical

(0~~2000)ppm

1 ppm

30s

Sulfureted hydrogen(H2S)

Electrochemical

(0~~500,1000)ppm

1 ppm

30s

Sulfur dioxide(SO2)

Electrochemical

(0~~100.0) ppm

0.1 ppm

30s

Nitrogen dioxide(NO2)

Electrochemical

(0~~100.0) ppm

0.1 ppm

30s

Chlorine(Cl2)

Electrochemical

(0~~100.0) ppm

0.1 ppm

30s

Hydrogen cyanide (HCN)

Electrochemical

(0~~30) ppm

0.1 ppm

30s

Hydrogen(H2)

Electrochemical

(0~~2000) ppm

1 ppm

30s

Ammonia(NH3)

Electrochemical

(0~~100) ppm

1 ppm

60s

Hydrogen fluoride(HF)

Electrochemical

(0~~10.0) ppm

0.1 ppm

50s

Phosphine(PH3)

Electrochemical

(0~~1000) ppm

1 ppm

30s

Organic vapor(VOCs)

PID

(0~~1000) ppm

1 ppm

30s

Hydrochloric acid (HCl)

Electrochemical

(0~~100.0) ppm

0.1 ppm

30s

Ozone(O3)

Electrochemical

(0~~10.0) ppm

0.1 ppm

30s

Carbon Dioxide(CO2)

Infrared

(0~~10000)ppm

100ppm

30s

(0~~5%,20%,40%,100%) Vol.

0.1 %Vol.

30s

Formalin(CH2O)

Electrochemical

(0~~30.0) ppm

0.1 ppm

40s
